Description

Extend your AutoCAD linetype library for free with our custom LIN file and DWG sample collection. This download includes standard ISO 128 linetypes (continuous, dashed, dash-dot, centre, phantom), as well as custom linetypes featuring text labels (GAS, WATER, ELECTRIC, FOUL, STORM), pictogram symbols, and colour-coded utility mapping styles.

LIN files install directly into AutoCAD’s support folder and are immediately selectable in the LINETYPE manager. Sample DWG sheets demonstrate each linetype at typical drawing scales.

Completely free, AutoCAD 2010 and above (including LT). An often-overlooked but genuinely useful free download for any drawing office wanting to standardise linetype usage across projects.
